Smd 5050

Značajke:

Značajke visoke stabilnosti

Stupanj otpornosti na vlagu MSL2a

5050 bijelih žarulja pakirano je od ekološki prihvatljivih materijala

U skladu s EU ROHS standardom

Specifikacije za Smd 5050:

5050 LED SERIJA SPECIFIKACIJA
ime proizvoda	Svijetla boja	CCT/valna duljina	napon	Trenutno	Lumen	Napomena
5050 Bijela LED dioda	Zlatno žuta	1800-2000K	3V/9V	60mA/20mA	18-24LM	CRI80,90
5050 Bijela LED dioda	Bijela	3000-7000K	3V/9V	60mA/20mA	20-28LM	CRI80,90,96 plus
5050 UV LED	UV	390-400nm	2.8-3.4V	60 mA	/	Epileds čip
5050 Plava LED dioda	Plava	450-470nm	2.8-3.4V	60 mA	800-1600mcd	Epistar/San'an Chip
5050 Zelena LED dioda	zelena	520-530nm	2.8-3.4V	60 mA	2000-4500mcd
5050 Žuta LED dioda	Žuto/jantarno	590-610nm	2.8-3.4V	60 mA	800-2000mcd
5050 crvena LED dioda	Crvena	620-630nm	2.8-3.4V	60 mA	800-2000mcd
5050 Far Red	Far Red	660-665nm	2.8-3.4V	60 mA	800-1000mcd	Epileds čip
5050 PC plava	Fosforno plava	450-470nm	2.8-3.4V	60 mA	5-9LM	Prilagođeni WD, WP
5050 PC zelena	Fosforno zelena	510-530nm	2.8-3.4V	60 mA	20-22LM
5050 PC boja	Fosforno jantarno/crveno	600-630nm	2.8-3.4V	60 mA	8-15LM
5050 RGB LED	RGB	R: 620-630nm, 2.0-2.4V, 20mA, 300-900mcd G: 520-530nm, 2.8-3.4V, 20mA, 600-1600mcd B: 460-470nm, 2.8-3.4V, 20mA, 200-600mcd				Epistar/San'an Chip
5050 RGBW LED	RGBW	R: 620-630nm, 2.0-2.4V, 20mA, 500-600mcd G: 520-530nm, 2.8-3.4V, 20mA, 1200-1500mcd B: 460-470nm, 2.8-3.4V, 20mA, 400-500mcd W: 3000-6000K, 2.8-3.4V, 30mA, 9-10LM				Epistar/San'an Chip
